Light source
＆#8226; Color light: 672 x 0.5W RGB LED
＆#8226; White light: 112 x 3W CW LED
Power supply : 420W
Features
32 color light zones can be controlled individually
16 white light zones can be controlled individually
Excellent color mixing function
Powerful high-output strobe effect
Built-in splicing pins for fast splicing and alignment
Electronic atomization effect
0-100% smooth dimming function(4 dimmer curve- Linear, Square Law, Inv SQ Lawor S Curve)
Optical system
Efficient optical system
Beam angle:
Color light beam angle: 101°
White light beam angle: 108°
Spot angle:
Color light spot angle: 149°
White light spot angle: 152°
Control and program
4 touch buttons
Control panel: 1.77 color screen display
Control protocol: DMX512, RDM（Art-Net, sACN optional）
DMX channel mode: 11
Control channels: 7/15/21/39/112/17/33/65/68/117/70
Software upgrade: Update software via DMX connection
Construction
DMX link: 3pin DMX XLR with daisy chain connection
Power link: Powercon In/out
Protection rate: IP65
Housing: Die-cast aluminum and pure aluminum with folderable clamp
Physical
Dimension: 1007*121*150mm Net Weight: 8kg
